Vogele Super 2100-2 2100-3 Asphalt Paver Vogele Vögele Super 1900 crawler asphalt paver

Vogele Super 2100-2  2100-3   Asphalt Paver Vogele   Vögele Super 1900 crawler asphalt paver
Vogele Super 2100-2  2100-3   Asphalt Paver Vogele   Vögele Super 1900 crawler asphalt paver Vogele Super 2100-2  2100-3   Asphalt Paver Vogele   Vögele Super 1900 crawler asphalt paver Vogele Super 2100-2  2100-3   Asphalt Paver Vogele   Vögele Super 1900 crawler asphalt paver Vogele Super 2100-2  2100-3   Asphalt Paver Vogele   Vögele Super 1900 crawler asphalt paver Vogele Super 2100-2  2100-3   Asphalt Paver Vogele   Vögele Super 1900 crawler asphalt paver Vogele Super 2100-2  2100-3   Asphalt Paver Vogele   Vögele Super 1900 crawler asphalt paver

Large Image :  Vogele Super 2100-2 2100-3 Asphalt Paver Vogele Vögele Super 1900 crawler asphalt paver

Product Details:
Place of Origin: USA、JAPAN UK
Brand Name: VOGELE
Certification: CE,ISO
Model Number: 2100-3
Payment & Shipping Terms:
Minimum Order Quantity: 1.00
Price: USD1.0
Packaging Details: Whatsapp: +8615021099979
Delivery Time: Whatsapp: 008615021099979
Payment Terms: Whatsapp: +8615021099979
Supply Ability: Whatsapp: +8615021099979
Detailed Product Description
Year: 2021 HOUR: 6201
CONDITION: USED TYPE: Asphalt

 Vogele Super 2100-2  2100-3   Asphalt Paver Vogele   Vögele Super 1900 crawler asphalt paver 0Vogele Super 2100-2  2100-3   Asphalt Paver Vogele   Vögele Super 1900 crawler asphalt paver 1Vogele Super 2100-2  2100-3   Asphalt Paver Vogele   Vögele Super 1900 crawler asphalt paver 2Vogele Super 2100-2  2100-3   Asphalt Paver Vogele   Vögele Super 1900 crawler asphalt paver 3



Product Feature

SUPER 1900-3 L – The highlights of the new generation

The tracked SUPER 1900-3 L is a model of the modern “Dash 3” paver generation from VÖGELE. The machine features a unique design as well as ergonomic operating comfort and high performance with minimum consumption. When developing this road paver, a special focus was on ergonomic, economic and ecological aspects. The “VÖGELE EcoPlus” package for a low carbon footprint, for instance, significantly reduces both fuel consumption and noise levels.

  • Maximum pave width up to 11m
  • Laydown rate up to 900 tonnes/h
  • Transport width 3m
  • ”VÖGELE EcoPlus“ low-emissions package for a low carbon footprint significantly reduces fuel consumption and noise levels
  • ErgoPlus 3 with a number of additional ergonomic and functional advantages
  • Powerful Cummins engine of the very latest generation
  • The powerful, oil-cooled generator is directly driven by the splitter gearbox and therefore maintenance-free
  • Extra long material hopper and chassis


Product Parameter

  SUPER 1900-3 L
Engine 6-cylinder diesel engine, liquid-cooled6-cylinder diesel engine, liquid-cooled
Manufacturer CumminsCummins
Type QSB 6.7 C-203QSB 6.7 C-203
Emissions Standard EU Stage 3a, US EPA Tier 3EU Stage 3a, US EPA Tier 3
Output -
Nominal 151kW / 2,000rpm179 hp / 2,000 rpm
ECO Mode 153kW / 1,700rpm205 hp / 1,700 rpm
Fuel Tank 400 litres106 gal. (US)


Crawler Tracks provided with rubber padsprovided with rubber pads
Ground Contact 3,060mm x 305mm10 ft. 1 in. x 1 ft.
Track Tension Adjuster spring assemblyspring assembly
Track Rollers lifetime grease lubricatedlifetime grease lubricated
Traction Drive hydraulic, separate drive and electronic control provided for each crawler trackhydraulic, separate drive and electronic control provided for each crawler track
Speeds
Pave up to 25m/minup to 82 fpm
Travel up to 4.5km/hup to 2.8 mph

Hopper Capacity 15 tonnes33,070 Ibs.
Width 3,265mm10 ft. 9 in.
Feed Height 550mm (bottom of material hopper)22 in. (bottom of material hopper)
Push-Rollers oscillating, displaceable forwards by 75mm and 150mmoscillating, displaceable forwards by 75 mm and 150 mm

Conveyors 2, with replaceable feeder bars, conveyor movement reversible for a short time2, with replaceable feeder bars, conveyor movement reversible for a short time
Drive separate hydraulic drive provided for each conveyorseparate hydraulic drive provided for each conveyor
Speed up to 31m/min., infinitely variable (manual or automatic)up to 31m/min., infinitely variable (manual or automatic)
Augers 2, with replaceable auger blades, auger rotation reversible2, with replaceable auger blades, auger rotation reversible
Diameter 420mm17 in.
Drive separate hydraulic drive provided for each augerseparate hydraulic drive provided for each auger
Speed 79rpm79 rpm
Height hydraulic by 15cmhydraulic by 6 in.
Lubrication centralized lubrication system with electrically driven grease pump for conveyor and auger bearingscentralized lubrication system with electrically driven grease pump for conveyor and auger bearings

AB 600(TV)
Basic Width 3m9 ft. 10 in.
Infinitely Variable Range 3m up to 6m9 ft. 10 in. up to 19 ft. 8 in.
Maximum Width(TV) 10m32 ft. 9 in.
SB 300 (TV, TP1)
Basic Width 3m9 ft. 9 in. 10 in.
Maximum Width(TV, TP1) 11m9 ft. 9 in. 10 in.
Layer Thickness up to 40cm (SB 300)up to 40cm (SB 300)
Screed Heating electric by heating rodselectric by heating rods
Power Supply three-phase A.C. generatorthree-phase A.C. generator

Length tractor unit with screedtractor unit with screed
AB 600(TV) 6.96m22 ft. 19 in.
AB 600(TP1) 7.09m22 ft. 19 in.
SB 300 (TV, TP1) 6.85m21 ft. 77 in.
Weight tractor unit with screedTractor Unit with Screed
AB 600(TV) pave width up to 6m 21.8 tonnespave width up to 19.68 ft. 48,060.78 Ibs.
  pave width up to 10m 26.2 tonnespave width up to 32.81 ft. 57,761.12 Ibs.
