mini truck STEEL TRACK CRAWLER WATER WELL DRILLING machine portable truck mounted water well drilling rig

Large Image : mini truck STEEL TRACK CRAWLER WATER WELL DRILLING machine portable truck mounted water well drilling rig

Product Details:

Place of Origin:	CHINA
Brand Name:	SANROCK
Certification:	ISOO 90001
Model Number:	985

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	USD1
Packaging Details:	container
Delivery Time:	7-15 working days
Payment Terms:	D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability:	300 units per month

Contact Now

Detailed Product Description

Type:	High Pressure Crawler Drill,Drill Shank,Agricultural Hydroponics,Core Drilling Rig	After-sales Service Provided:	Engineers Available To Service Machinery Overseas,Video Technical Support
Warranty:	12 Months	Usage:	Water Well
Power Type:	Diesel	Condition:	New
Certification:	ISO9001,ISO,ENERGY SAVING,CE	Product Name:	200m Pneumatic Tractor Mounted Water Well Drilling Rig Machine Price
Drilling Depth:	300m

250m 300m FY300A/ FY300 STEEL TRACK CRAWLER WATER WELL DRILLING machine portable truck mounted water well drilling rig

300m FY300A/ FY300 STEEL TRACK CRAWLER WATER WELL DRILLING machine portable water well drilling rigs

DESCRIPTION

400M depth Water Well Drilling Rig

Product Features

● This model rig uses full hydraulic control, and the Top drive to drive the rotation of drilling tools with very high drilling efficiency.

● Reasonable overall layout uses the tractor-mounted or full ground chassis for transportation with good maneuverability.

● Very flexible in difficult roads and can be widely used in many fields such as resource exploration of hydrology wells, coalbed methane, the shallow

layer of shale gas, terrestrial heat, etc, and can also be used for coal-mine gas exploitation salvage work.

● The top-mounted driving head principal shaft has a great drift diameter, suitable for many kinds of construction work such as slurry drilling, air
drilling, and air foam drilling, meeting the demands for well-drilling at different terrain strata.

SPECIFICATION

SPECIFICATIONS

FY300A CRAWLER WATER WELL DRILLING RIG

Drilling Depth	300m
Drilling Diameter	140-325mm
One-Time Advance Length	3.40m
Walking Speed	2.50km/h
Climbing Angles	30 degree
Engine Power	76KW
Work Air Pressure	1.7-3.0 Mpa
Air Consumption	17-35m3/min
Drill Pipe Length	2m, 3m
Drill Pipe Diameter	76mm, 89mm, 102mm
Rig Lifting Force	16 ton
Rotary Speed	40-70 rpm
Rotary Torque	5700-7500 N.m
Weight	7000KG
Dimensions	410019502600mm

FY300 CRAWLER WATER WELL DRILLING RIG

Drilling Depth	300m
Drilling Diameter	140-325mm
One-Time Advance Length	6.60m
Walking Speed	2.50km/h
Climbing Angles	30 degree
Engine Power	84KW
Work Air Pressure	1.7-3.3 Mpa
Air Consumption	17-35m3/min
Drill Pipe Length	2m, 3m, 6m
Drill Pipe Diameter	89mm, 102mm
Rig Lifting Force	20 ton
Rotary Speed	55-115 rpm
Rotary Torque	6200-8500 N.m
Weight	9000KG
Dimensions	590020002850mm

==============================================

please feel free contact us, whatsapp/wechat::008615021099979

====================================================

FY600/F800 CRAWLER WATER WELL DRILLING RIG

FY600/F800 Crawler Water Well Drilling Rig

DESCRIPTION

600M 800M depth Water Well Drilling Rig
mini truck STEEL TRACK CRAWLER WATER WELL DRILLING machine portable truck mounted water well drilling rig 0
Product Features

● This model rig uses full hydraulic control, and the Top drive to drive the rotation of drilling tools with very high drilling efficiency.

● Reasonable overall layout uses the tractor-mounted or full ground chassis for transportation with good maneuverability.

● Very flexible in difficult roads and can be widely used in many fields such as resource exploration of hydrology wells, coalbed methane, the shallow
layer of shale gas, terrestrial heat, etc, and can also be used for coal-mine gas exploitation salvage work.
● The top-mounted driving head principal shaft has a great drift diameter, suitable for many kinds of construction work such as slurry drilling, air
drilling, and air foam drilling, meeting the demands for well-drilling at different terrain strata.

SPECIFICATION

FY600 CRAWLER WATER WELL DRILLING RIG

Drilling Depth	600m
Drilling Diameter	140-350mm
One-Time Advance Length	6.60m
Walking Speed	2.50km/h
Climbing Angles	30 degree
Engine Power	118KW
Work Air Pressure	1.7-3.5 Mpa
Air Consumption	17-42m3/min
Drill Pipe Length	2m, 3m, 6m
Drill Pipe Diameter	102mm, 108mm, 114mm
Rig Lifting Force	28 ton
Rotary Speed	45-115 rpm
Rotary Torque	8500-11000 N.m
Weight	12000KG
Dimensions	600022002850mm

FY800 CRAWLER WATER WELL DRILLING RIG

Drilling Depth	700m
Drilling Diameter	140-400mm
One-Time Advance Length	6.60m
Walking Speed	2.50km/h
Climbing Angles	30 degree
Engine Power	140KW
Work Air Pressure	1.7-3.5 Mpa
Air Consumption	17-42m3/min
Drill Pipe Length	2m, 3m, 6m
Drill Pipe Diameter	102mm, 108mm, 114mm
Rig Lifting Force	30 ton
Rotary Speed	55-120 rpm
Rotary Torque	8850-13150 N.m
Weight	13000KG
Dimensions	610022002900mm

==================================================================================
please feel free contact us, whatsapp/wechat::008615021099979

=====================================================

FY600 CRAWLER WATER WELL DRILLING RIG

Drilling Depth	600m
Drilling Diameter	140-350mm
One-Time Advance Length	6.60m
Walking Speed	2.50km/h
Climbing Angles	30 degree
Engine Power	118KW
Work Air Pressure	1.7-3.5 Mpa
Air Consumption	17-42m3/min
Drill Pipe Length	2m, 3m, 6m
Drill Pipe Diameter	102mm, 108mm, 114mm
Rig Lifting Force	28 ton
Rotary Speed	45-115 rpm
Rotary Torque	8500-11000 N.m
Weight	12000KG
Dimensions	600022002850mm

FY800 CRAWLER WATER WELL DRILLING RIG

Drilling Depth	700m
Drilling Diameter	140-400mm
One-Time Advance Length	6.60m
Walking Speed	2.50km/h
Climbing Angles	30 degree
Engine Power	140KW
Work Air Pressure	1.7-3.5 Mpa
Air Consumption	17-42m3/min
Drill Pipe Length	2m, 3m, 6m
Drill Pipe Diameter	102mm, 108mm, 114mm
Rig Lifting Force	30 ton
Rotary Speed	55-120 rpm
Rotary Torque	8850-13150 N.m
Weight	13000KG
Dimensions	610022002900mm
