Product Details:
Payment & Shipping Terms:
|
| Condition: | New | Dimension(l*w*h): | Specific Model |
|---|---|---|---|
| Product Name: | Factory Produced Stone Aggregate Crushing Machine Plant | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Color: | Customizable | Power(w): | 110kw |
| Name: | Quarry Stone Crusher Plant | Max Feeding Size: | 300-500mm |
6S series vertical shaft impact crusher is based on the original high-performance VSI series and combined with actual running condition under different working conditions as well as operator’s feedback.It is advanced with low cost, high crushing ratio and intelligent operation.We improve the performance of 6S series vertical shaft impact crusher by perfecting the feeding mode,optimizing the crushing chamber, adapting new-design rotor,equipping with lifting device etc.Thanks to above new advantages, it reduces flow resistance of stones, increases throughput capacity,reduces wear rate of spare parts,increases utilization ratio,extends maintenance cycle and decreases repair time.6S series vertical shaft impact crusher has become the most advanced and most representative high-performance sand making equipment in China.
This mobile crushing station consists of vibrating feeder and jaw crusher. It plays a role of primary crushing stage, which can crush the hard stone with size around 700mm into small aggregates size range from 80mm-140mm. Its capacity is around 110-320t/h.
The stone production line (500tph-600tph) mainly consists of vibrating feeder, jaw crusher, 2 sets impact crushers, 2sets vibrating screens, etc. In order to meet the large-output requirement, this configuration is energy-saving and high-efficiency. It can crush medium hard rock into stone at the rate of 500TPH to 600TPH.
Specifications
| No. | Equipment | Model | Quantity | Power(Kw) |
| 1 | Vibrating Feeder | GZD1100X4200 | 1 | 15-18.5 |
| 2 | Jaw Crusher | PE750X1060 | 1 | 90-110 |
| 3 | Chassis | Tri-axial | 1 |
(100-150TPH) Hard Rock Mobile Crushing Screening &Washing Plant Sand Making Plant
please feel free contact us by whatsapp: 008615021099979
(wechat/Viber/line/IMO/facebook)
Feature
1.Manufacturing technique is of world class
2.The movable jaw assembly is of more advanced technology. It adopts high quality welding technology, and the eccentric shaft is elaborate
3.Integral cast steel structure is adopted for bearing seat to ensure the complete match with the frame
4.Finite Element Analysis is adopted to strengthen the crusher
5.The crushing chamber adopts "V" shape structure, which makes the feeding port's actual width be in accordance with the nominal
6.Discharging port adjustment is quicker and more convenient. Wedge block adjustment device is easier, safer and faster
7.Larger and more wearable main bearing is used to lengthen the service life; The bearing capacity is higher and effective labyrinth seal also lengthens the lifespan
8.The teeth protection plate increases the length of jaw plate
Specifications
| Model | 6S-9832 | 6S-1250 | |
| Capacity(T/H) | Center and ring feeding | 450-520 | 650-800 |
| Center feeding | 225-260 | 325-400 | |
| Max. feeding length(mm) | Soft material | ＜50 | ＜50 |
| Hard material | ＜45 | ＜45 | |
| Rotation speed(r/min) | 1360-1510 | 1100-1310 | |
| Power of two motors(Kw) | 160×2 | 250×2 | |
| Dimension(mm) | 4750×2547×2850 | 5200×2830×3350 | |
| Power source | 380V50Hz | ||
| Monitoring range of vibration sensor | 0.1-20mm/ continuous and adjustable | ||
| Hydraulic lubrication station | Motor power(Kw) | 2×0.31 | |
| Safety | Complementary double pumps ensure oil supply; no oil flow; no-oil-hydraulic-automatic-protection; water cooling; heating boot of motor in winter | ||
| Dimension(mm) | 820×520×1270 | ||
| Power of tank heater(Kw) | 2 | ||
