Sand Making Plant PE Jaw Crusher vibrating feeder primary crushing vibrating feeder stone production can crush

China Sand Making Plant PE Jaw Crusher vibrating feeder  primary crushing vibrating feeder stone production can crush supplier
Sand Making Plant PE Jaw Crusher vibrating feeder  primary crushing vibrating feeder stone production can crush supplier Sand Making Plant PE Jaw Crusher vibrating feeder  primary crushing vibrating feeder stone production can crush supplier Sand Making Plant PE Jaw Crusher vibrating feeder  primary crushing vibrating feeder stone production can crush supplier Sand Making Plant PE Jaw Crusher vibrating feeder  primary crushing vibrating feeder stone production can crush supplier Sand Making Plant PE Jaw Crusher vibrating feeder  primary crushing vibrating feeder stone production can crush supplier

Large Image :  Sand Making Plant PE Jaw Crusher vibrating feeder primary crushing vibrating feeder stone production can crush

Product Details:

Place of Origin: SHANGHAI
Brand Name: SHQI
Certification: ISOO 90001.0
Model Number: JXL32656

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: USD**
Packaging Details: container
Delivery Time: 28 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100 units per month
Contact Now
Detailed Product Description
Condition: New Dimension(l*w*h): Specific Model
Product Name: Factory Produced Stone Aggregate Crushing Machine Plant After-sales Service Provided: Engineers Available To Service Machinery Overseas
Color: Customizable Power(w): 110kw
Name: Quarry Stone Crusher Plant Max Feeding Size: 300-500mm

PE Jaw Crusher

The jaw crusher is mainly used for crushing the stones of which largest compression resistance is 320MPa. This series is complete in specifications and the first choice of primary crushing equipment. Its structure iseasy and solid. It is easy to maintain and enjoys satisfactory performance. The jaw crusher is widely used in the industries of mining, metallurgy, building, highway, railway, water conservancy and chemical.

Sand Making Plant PE Jaw Crusher vibrating feeder  primary crushing vibrating feeder stone production can crush

please feel free contact us by whatsapp: 008615021099979
(wechat/Viber/line/IMO/facebook)

(100-150TPH) Hard Rock Mobile Crushing Mobile Jaw Crusher Portable Crushing Plant

This mobile crushing station consists of vibrating feeder and jaw crusher. It plays a role of primary crushing stage, which can crush the hard stone with size around 700mm into small aggregates size range from 80mm-140mm. Its capacity is around 110-320t/h.

(500TPH-600TPH) Medium Hard Rock

The stone production line (500tph-600tph) mainly consists of vibrating feeder, jaw crusher, 2 sets impact crushers, 2sets vibrating screens, etc. In order to meet the large-output requirement, this configuration is energy-saving and high-efficiency. It can crush medium hard rock into stone at the rate of 500TPH to 600TPH.

Sand Making Plant PE Jaw Crusher vibrating feeder  primary crushing vibrating feeder stone production can crush


Specifications



No.EquipmentModelQuantityPower(Kw)
1Vibrating FeederGZD1100X4200115-18.5
2Jaw CrusherPE750X1060190-110
3ChassisTri-axial1


(100-150TPH) Hard Rock Mobile Crushing Screening &Washing Plant Sand Making Plant



please feel free contact us by whatsapp: 008615021099979
(wechat/Viber/line/IMO/facebook)



  •
    Feature
    1.Deep crushing cavity, high capacity
    2.High crushing ratio, homogeneous particle size
    3.Gasket adjusting device is reliable and convenient, large adjusting range and is more flexible
    4.Lubrication system is safe, parts are easy to change, it's easy to maintain
    5.Simple structure, low cost
    6.Energy saving: single machine saves 15%-30%, the whole system doubles
    7.Wide adjustment range of discharging port meets different customers' demands
    8.Low noise and little dust
    • PE Jaw Crusher0
    • PE Jaw Crusher1
    • PE Jaw Crusher2
    • PE Jaw Crusher3



    Specifications



    Model

    Opening Size
    (mm)

    Max. Feeding Size
    (mm)

    Discharge Size
    (mm)

    Capacity
    (t/h)

    Power
    (kw)

    Dimension
    (mm)

    PE-250×400250×40020020-505-20151430×1310×1340
    PE-400×600400 ×60035040-10015-6030-371700×1732×1653
    PE-500×750500×75042550-10040-11045-552035×1921×2000
    PE-600×900600 ×90048065-16090-18055-752290×2206×2370
    PE-750×1060750 ×106063080-140110-32090-1102655×2302×3110
    PE-900×1200900×120075095-180220-4501323475×2826×3025
    PE-1000×12001000×120085095-190230-5001323800×3166×3045
    PE-1200×15001200×15001020150-300400-8002204930×3148×3703
    PE-1500×18001500×18001200220-350450-10003555630×3210×4120
    PEX-150×250150×25012510-401-35.5896×745×935
    PEX-150×750150×75012518-485-16151200×1500×1200
    PEX-250×750250×75021025-6015-3022-301667×1545×1020
    PEX-250×1000250×100021025-6015-5030-371550×1964×1380
    PEX-250×12001200×25021025-6020-6037-452192×1900×1950
