Product Details:
Payment & Shipping Terms:
|
| Made In: | USA | Hours: | 5000 |
|---|---|---|---|
| Bucket:: | 0.5m3 | Year: | 1995 |
| Engine | ||
| Make | Mitsubishi | |
| Model | 4D32 | |
| Gross Power | hp | kw |
| Net Power | 54 hp | 40.3 kw |
| Power Measured @ | 1800 rpm | |
| Displacement | 217.9 cu in | 3.6 L |
| Operational | ||
| Operating Weight | 15256 lb | 6920 kg |
| Fuel Capacity | 29.1 gal | 110 L |
| Cooling System Fluid Capacity | 4.2 gal | 16 L |
| Hydrauilc System Fluid Capacity | 27.7 gal | 105 L |
| Engine Oil Capacity | 2.4 gal | 9 L |
| Swing Drive Fluid Capacity | 1.1 gal | 4 L |
| Operating Voltage | 12 V | |
| Alternator Supplied Amperage | 50 amps | |
| Hydraulic System Relief Valve Pressure | 4551 psi | 31378 kPa |
| Hydraulic Pump Flow Capacity | 35.4 gal/min | 134 L/min |
| Swing Mechanism | ||
| Swing Speed | 13.5 rpm | |
| Undercarriage | ||
| Number of Shoes per Side | 42 | |
| Shoe Size | 17.7 in | 450 mm |
| Number of Track Rollers per Side | 5 | |
| Ground Pressure | 4.7 psi | 32.4 kPa |
| Max Travel Speed | 2.5 mph | 4.1 km/h |
| Drawbar Pull | 10141 lb | 45.1 kN |
| Track Gauge | 5.7 ft in | 1750 mm |
| Buckets | ||
| Reference Bucket Capacity | 0.37 yd3 | 0.28 m3 |
| Minimum Bucket Capacity | 0.18 yd3 | 0.14 m3 |
| Maximum Bucket Capacity | 0.44 yd3 | 0.34 m3 |
| Boom/Stick Option (HEX) 1 | ||
| Boom/Stick Option (HEX) 1 | One-piece boom w/ Stick 4'6" (1390mm) | |
| Max Digging Depth | 12.4 ft in | 3780 mm |
| Max Reach Along Ground | 19.5 ft in | 5930 mm |
| Max Cutting Height | 21.3 ft in | 6505 mm |
| Max Loading Height | 14.6 ft in | 4460 mm |
| Max Vertical Wall Digging Depth | 10.1 ft in | 3070 mm |
| Boom/Stick Option (HEX) 2 | ||
| Boom/Stick Option (HEX) 2 | One-piece boom w/ Stick 5'11" (1720mm) | |
| Max Digging Depth | 13.5 ft in | 4110 mm |
| Max Reach Along Ground | 20.5 ft in | 6245 mm |
| Max Cutting Height | 22.1 ft in | 6725 mm |
| Max Loading Height | 15.3 ft in | 4660 mm |
| Max Vertical Wall Digging Depth | 11.6 ft in | 3530 mm |
| Boom/Stick Option (HEX) 3 | ||
| Boom/Stick Option (HEX) 3 | One-piece boom w/ Stick 7'8" (2210mm) | |
| Max Digging Depth | 15.1 ft in | 4595 mm |
| Max Reach Along Ground | 22 ft in | 6720 mm |
| Max Cutting Height | 23 ft in | 7025 mm |
| Max Loading Height | 16.3 ft in | 4960 mm |
| Max Vertical Wall Digging Depth | 13 ft in | 3965 mm |
| Dimensions | ||
| Width to Outside of Tracks | 7.4 ft in | 2260 mm |
| Height to Top of Cab | 8.4 ft in | 2570 mm |
| Ground Clearance | 0.98 ft in | 300 mm |
| Counterweight Clearance | 2.6 ft in | 780 mm |
| Tail Swing Radius | 5.7 ft in | 1750 mm |
| Length of Track on Ground | 6.6 ft in | 2000 mm |
